DataGrip

DataGrip supports querying both internal data and external data in StarRocks.

tip

DataGrip docs

You can connect to StarRocks from DataGrip using either the native StarRocks JDBC driver (recommended) or the MySQL driver.

Connect using the StarRocks JDBC driver (recommended)

The StarRocks JDBC driver provides accurate metadata discovery, which enables schema browsing, auto-complete, and table introspection in DataGrip.

Prerequisites

Download the StarRocks JDBC driver JAR. See StarRocks JDBC Driver for download instructions.

Steps

1. In DataGrip, go to File > Data Sources (or click the Database icon in the toolbar).

2. Click + and select Driver and Data Source.

3. In the Drivers tab, click + to create a new driver.

   • Set the Name to StarRocks.
   • Under Driver Files, click + and add the StarRocks JDBC driver JAR you downloaded.
   • Set the Class to com.starrocks.cj.jdbc.Driver.
   • Set the URL template to:

     jdbc:starrocks://{host}:{port}/{catalog}.{database}

   • Click OK to save the driver.



4. Back in the Data Sources tab, click + and select the StarRocks driver you just created.

5. Configure the connection settings:

   • Host: the FE host IP address of your StarRocks cluster.
   • Port: the FE query port of your StarRocks cluster, for example, 9030.
   • Catalog: the name of the target catalog. Use default_catalog for internal tables, or the name of an external catalog.
   • Database: the name of the target database within the catalog.
   • User: the username to log in to your StarRocks cluster, for example, admin.
   • Password: the password to log in to your StarRocks cluster.

6. Click Test Connection to verify the settings, then click OK.

Connect using the MySQL driver

The MySQL driver is a fallback for the StarRocks JDBC driver.

Create a data source in DataGrip. Note that you must select MySQL as the data source.

The parameters that you need to configure are described as follows:

• Host: the FE host IP address of your StarRocks cluster.
• Port: the FE query port of your StarRocks cluster, for example, 9030.
• Authentication: the authentication method that you want to use. Select Username & Password.
• User: the username that is used to log in to your StarRocks cluster, for example, admin.
• Password: the password that is used to log in to your StarRocks cluster.
• Database: the data source that you want to access in your StarRocks cluster. The value of this parameter is in the <catalog_name>.<database_name> format.
  • catalog_name: the name of the target catalog in your StarRocks cluster. Both internal and external catalogs are supported.
  • database_name: the name of the target database in your StarRocks cluster. Both internal and external databases are supported.
